4060 ST NX

HERBIE FLIP

140mm Rear / 150mm Front Travel, 29” Wheels
RockShox Lyrik Select / RockShox Super Deluxe Select+ Suspension
SRAM NX Eagle Drivetrain, SRAM Code R Brakes

Regular priceCHF 4,999.00
CHF /
Tax included.

SKU: 30005164
Size
  • In stock, ready to ship
  • Inventory on the way

4060 ST NX

Parts & Accessories

Add a Shock

  • Shipped to your local bike shop
  • FAQ
A trail bike that punches way above its class, the 4060 ST NX gives you the confidence to take on the toughest trails right out of the box. A lightweight full-carbon frame with quality suspension components is happy to go with the flow or get deep-down and gnarly. The bulletproof build kit means you’re good to go from the get-go and with everything you need and nothing you don’t, you can focus on having fun on the trail ahead.

Technology

Technical Details

Frameset

Frame:
SCOR 4060 Full Carbon Frame | Lower-Link Driven Instant Center Linkage | 140 / 160mm Rear Wheel Travel | Fully Guided Internal Cable Routing | Stash Box | Boost 148 | SRAM UDH | Lower ISCG 05 Mount / Chainguide

Fork:
RockShox Lyrik Select RC | 150mm Travel | 44mm Rake

Suspension

Front Suspension:
RockShox Lyrik Select RC | 150mm Travel | 44mm Rake

Rear Suspension:
RockShox Super Deluxe Select+ RT Hydraulic Bottom Out | 205 x 57.5mm Trunnion

Cockpit

Stem:
SCOR Alloy Stem | 31.8mm Bar Bore | 35 mm Length | 0° Angle

Handlebar:
SCOR Alloy Bar | 31.8mm Clamp | 800mm Wide | 20mm Rise | 5° Upsweep | 9° Backsweep

Grips:
VP VPG-125A

Seat

Seatpost:
X-Fusion Manic | S 125mm | M 150mm | L / XL 170mm Travel

Saddle:
WTB Silverado Medium Steel SL

Drivetrain

Crankset:
SRAM Descendant 6K Eagle | 170 mm Length

Chainrings:
32T

Cassette:
SRAM NX PG-1230 Eagle

Cassette Size:
11-50T

Chain:
SRAM NX Eagle

Rear Derailleur:
SRAM NX Eagle

Shifters:
SRAM NX Eagle Trigger

Gears:
1 x 12

Bottom Bracket:
DUB Interface

Brakes

Brake Levers / Calipers:
SRAM Code R

Rotors:
SRAM Centerline | 6-Bolt

Rotor Size (F/R):
200mm

Wheels

Rims:
XDX-530 | 28 Spokes | 6061-T6 Alloy | Welded Joint | 30mm Internal Width | Tubeless ready

Hubs (F/R):
XDX-530 | 28 Spokes | Sealed Cartridge Bearings

Tires:
Maxxis Assegai 29 x 2.5" 3C MaxxTerra Exo TR (F) | Maxxis Dissector 29 x 2.4" 3C MaxxTerra Exo+ TR (R)

Tubeless Information:
Tubeless Ready Rims | Tubetype Tires

Additional Information

Tire Clearance:
Width: 64mm | Diameter: 750mm

ASTM Classification:
Level 4

System Weight Limit:
120kg

Size S M L XL
Rider Height 155 - 170 165 - 180 175 - 190 185 - 200
BB Drop (SLACK) 31 31 31 31
BB Drop (STEEP) 29 29 29 29
BB Height (SLACK) 338 338 338 338
BB Height (STEEP) 340 340 340 340
Chainstay 433 433 433 433
Fork Length 560 560 560 560
Fork Rake 44 44 44 44
Front Center (SLACK) 765 790 815 845
Front Center (STEEP) 752 777 802 832
Head Tube 87 99 115 127
HT Angle (SLACK) 64.5 64.5 64.5 64.5
HT Angle (STEEP) 65.5 65.5 65.5 65.5
Reach (SLACK) 440 465 490 520
Reach (STEEP) 436 461 485 516
Seat Tube 400 425 440 470
ST Angle @750mm Saddle Height (SLACK) 77 77 77 77
ST Angle @750mm Saddle Height (STEEP) 76.5 76.5 76.5 76.5
ST Angle Actual (SLACK) 69.4 69.4 69.4 69.4
ST Angle Actual (STEEP) 69 69 69 69
ST Angle Effective (SLACK) 78.5 78.5 78.5 78.5
ST Angle Effective (STEEP) 78 78 78 78
Stack (SLACK) 597 608 622 633
Stack (STEEP) 599 611 625 636
Stand Over Height (80 in Front of BB) 752 764 768 784
Stand Over Height (Lowest Point) 714 723 731 741
Top Tube (SLACK) 560 589 620 654
Top Tube (STEEP) 561 590 621 655
Wheelbase (SLACK) 1198 1223 1248 1278
Wheelbase (STEEP) 1185 1210 1235 1265
