4060 Z LT SLX


160mm Rear / 170mm Front Travel, 29” Wheels
RockShox ZEB Select / RockShox Super Deluxe Select Suspension
Shimano SLX Drivetrain, Shimano Deore Brakes

Regular priceCHF 7,499.00
Tax included.

SKU: 30002941
  • In stock, ready to ship
  • Inventory on the way
  • Shipped to your local bike shop
  • FAQ
With the power to play harder and the capacity to take you further the 4060 Z LT SLX serves up the gnarliest trails at a lightning pace. An enduro bike with extra e, this is the bike for those looking to surge up the toughest climbs and have energy in reserve to charge the descents. A full-carbon frame, quality suspension and a bulletproof selection of components mean you’re good to go from the get-go.

Technical Details


SCOR 4060 Z full carbon frame | Lower-Link Driven Instant Center linkage | 140 / 160mm rear travel | Fully guided internal cable routing | Boost 148 | SRAM UDH

RockShox ZEB Select RC | 170mm travel | 44mm rake


Front Suspension:
RockShox ZEB Select RC | 170mm travel | 44mm rake

Rear Suspension:
RockShox Super Deluxe Select | Rebound adjust


Drive Unit:
Shimano E-Bike Systems EP8 (DU-EP800)

Battery Pack:
Darfon 36V | 720Wh | Shimano E-Bike Systems service included

Drive Unit Control:
Shimano EP8 Left Switch Unit (SW-EM800-L)

Shimano EP8 Wireless Cycle Computer (SC-EM800)

Darfon Smart Plus 100-240V | 4A | EU


SCOR Alloy Bar | 31.8mm clamp | 800mm wide | 20mm rise | 5° upsweep | 9° backsweep


SCOR Alloy Stem | 3D forged | 31.6mm bar bore | 35mm lenght | 0deg angle


X-Fusion Manic | S 125mm | M 150mm | L / XL 170mm travel

Fizik Terra Alpaca X5


1 x 12

Shimano FC-EM600 | 165mm length | 34T chainring (SM-CRE80-12-B)

Shimano Deore (CS-M6100-12) | 10-51T

Shimano Deore (CN-M6100)

Rear Derailleur:
SHIMANO Deore SLX (RD-M7100) | 12 speed

SHIMANO Deore SLX (SL-M7100-R)


Brake Levers / Calipers:
Shimano Deore | BR-M6120 calipers | BL-M6100 levers

SHIMANO SM-RT66 rotors | 203mm


XDH-130 | 32 spokes | 6061-T6 alloy | welded joint | 30mm internal width | Tubeless ready

Hubs (F/R):
XDH-130 | 32 spokes | Sealed cartridge bearings

Maxxis Assegai 29 x 2.5" 3C MaxxGrip Exo+ TR (F) | Maxxis Dissector 29 x 2.4" 3C MaxxTerra DD TR (R)

Tubeless Information:
Tubeless ready rims | Tubeless tires

Additional Information

Tire Clearance:
Width: 64mm | Diameter: 750mm

ASTM Classification:
Level 4

Weight Limit:

Rider Height155 - 170165 - 180175 - 190185 - 200
Bar Drop
Bar Reach
Bar Rise
Bar Sweep
Bar Width
Base Bar Drop Flat Cockpit
Base Bar Drop V-Cockpit
Base Bar Reach Flat Cockpit
Base Bar Reach V-Cockpit
BB Drop
BB Drop (SLACK)19191919
BB Drop (STEEP)16161616
BB Height (SLACK)350350350350
BB Height (STEEP)353353353353
Crank Length
LT | BB Drop (SLACK)
LT | BB Drop (STEEP)
LT | BB Height (SLACK)
LT | BB Height (STEEP)
LT | Chainstay
LT | Fork Length
LT | Fork Rake
LT | Frame Size
LT | Front Center (SLACK)
LT | Front Center (STEEP)
LT | Head Tube
LT | HT Angle (SLACK)
LT | HT Angle (STEEP)
LT | Reach (SLACK)
LT | Reach (STEEP)
LT | Rider Height
LT | Seat Tube
LT | ST Angle @750mm Saddle Height (SLACK)
LT | ST Angle @750mm Saddle Height (STEEP)
LT | ST Angle Actual (SLACK)
LT | ST Angle Actual (STEEP)
LT | ST Angle Effective (SLACK)
LT | ST Angle Effective (STEEP)
LT | Stack (SLACK)
LT | Stack (STEEP)
LT | Stand Over Height (80 in Front of BB)
LT | Stand Over Height (Lowest Point)
LT | Top Tube (SLACK)
LT | Top Tube (STEEP)
LT | Wheelbase (SLACK)
LT | Wheelbase (STEEP)
ST | BB Drop (SLACK)
ST | BB Drop (STEEP)
ST | BB Height (STACK)
ST | BB Height (STEEP)
ST | Chainstay
ST | Fork Length
ST | Fork Rake
ST | Frame Size
ST | Front Center (SLACK)
ST | Front Center (STEEP)
ST | Head Tube
ST | HT Angle (SLACK)
ST | HT Angle (STEEP)
ST | Reach (SLACK)
ST | Reach (STEEP)
ST | Rider Height
ST | Seat Tube
ST | ST Angle @750mm Saddle Height (SLACK)
ST | ST Angle @750mm Saddle Height (STEEP)
ST | ST Angle Actual (SLACK)
ST | ST Angle Actual (STEEP)
ST | ST Angle Effective (SLACK)
ST | ST Angle Effective (STEEP)
ST | Stack (SLACK)
ST | Stack (STEEP)
ST | Stand Over Height (80 in Front of BB)
ST | Stand Over Height (Lowest Point)
ST | Top Tube (SLACK)
ST | Top Tube (STEEP)
ST | Wheelbase (SLACK)
ST | Wheelbase (STEEP)
Fork Length580580580580
Fork Rake44444444
Frame Size
Front Center
Front Center (SLACK)773798823853
Front Center (STEEP)761785810840
Head Tube8799115127
Head Tube Angle
HT Angle (SLACK)63.863.863.863.8
HT Angle (STEEP)65656565
Pad Reach Flat Cockpit
Pad Reach V-Cockpit
Pad Stack Flat Cockpit
Pad Stack V-Cockpit
Reach (SLACK)435459485515
Reach (STEEP)431456481511
Rear Center
Saddle Height Range
Seat Angle
Seat Tube400425440470
Seatpost Drop
Seatpost Length
Seatpost Offset
ST Angle @750mm Saddle Height (SLACK)76.576.576.576.5
ST Angle @750mm Saddle Height (STEEP)76767676
ST Angle Actual (SLACK)69696969
ST Angle Actual (STEEP)68.568.568.568.5
ST Angle Effective (SLACK)77.977.977.977.9
ST Angle Effective (STEEP)77.477.477.477.4
Stack (SLACK)601612626637
Stack (STEEP)603615629640
Stand Over Height (80 in Front of BB)759771775791
Stand Over Height (Lowest Point)722731739749
Standover Height
Stem Angle
Stem Length
Top Tube
Top Tube (SLACK)562590621655
Top Tube (STEEP)564592623657
Wheelbase (SLACK)1206123012551285
Wheelbase (STEEP)1193121712421272
